Product
Detail

SJZ-2513 UV Flatbed Printer

Selected Ricoh G6 printheads, high-precision 5PL ink dots, and a maximum firing frequency of 50KHz, to meet high-definition and high-speed printing needs, 24-hour uninterrupted continuous operation, saving consumables and reducing production costs.

选择规格数量

Descriptions

Parameter Overview

Machine Type: Inkjet UV Flatbed Printer
Application Scope: Various flat substrates with smooth surfaces
Machine Size: 2500*1300 mm (Effective Printing Platform)
Material Thickness: 0.1~140 mm
Print Colors: K+C+M+Y+Lc+Lm+V+W
Printhead Model: RICOH GEN6 Maximum
Printhead Quantity: 12 units
Printhead Layout: 4 rows Curing System: UV LED Curing System

Adhering to the corporate philosophy of 'In-depth Cooperation, Premium Quality, Continuous Innovation', our company has long dedicated itself to the research of digital control technology, color management technology and liquid material application technology.

The SJZ-2513UV high-speed UV flatbed printer embodies the R&D team’s technical research and accumulated expertise, delivering an all-in-one digital flatbed printing solution with outstanding stability and superior printing performance.

The printing platform adopts top-tier design standards, premium components and rigorous assembly processes to achieve ultra-high precision, guaranteeing photo-grade printing output. Equipped with multi-color configurations including KCMY, LcLm, white ink and varnish, this single machine fulfills all printing application demands at high speeds. It delivers an impressive, comfortable and memorable visual feast for all users.

Product Functions

▲ Configurable with 2 to 12 printheads to accommodate diverse printing requirements
▲ Grayscale printing technology; variable droplet sizes ranging from 5PL to 15PL, delivering rich, saturated colors and smooth color gradients.

▲ Extremely wide range of compatible substrates: acrylic, wood, glass, metal, leather, PVC, industrial film and many other materials.

▲ Up to 16 white ink printing modes, including base white coating, overprint white, spot color and more.

▲ Equipped with 3 special varnish printing modes.

▲ Three-layer simultaneous printing technology: one-step output of Color + White + Color or Color + White + Varnish to complete graphics in a single pass.

▲ Supports multi-color and speed combinations of KCMY + LcLm + White + Varnish, meeting all printing application demands with superior performance in one machine.

▲ Adopts grayscale printing technology. Automatically adjustable ink droplet sizes cut ink consumption by 30% to 50%.

▲ Compatible with eco-friendly LED UV ink.

Technical Specifications

Item	Parameter
Model	SJZ-2513
Printhead Configuration	Optional 2–12 RICOH GEN6 printheads; 2 GEN6 printheads as standard
Max Printing Size	2500*1300 mm
Print Resolution	720600 dpi / 720900 dpi / 720*1200 dpi
Printing Technology	Piezoelectric inkjet + Grayscale printing technology
Ink Supply System	Automatic ink feeding, with low ink reminder alarm
Curing System	Water-cooled dual-lamp LED UV curing lamps
Negative Pressure System	Dual automatic adjustable negative pressure system
Ink Type	LED UV curable ink
Ink Color Option	K, C, M, Y, Lc, Lm, V, W (optional)
Single Ink Tank Volume	2 L
RIP Software	Photoprint
Color Management	International standard ICC color control; user-adjustable color curve & ink density
Operating System	Windows 10 64-bit, USB 2.0/3.0, Hard disk ≥500G
Supported File Formats	Tiff, Jpeg, Postscript, EPS, PDF, etc.
Printable Media Thickness	0.1–140 mm
Axis Motor Configuration	X-axis: Linear motor; Y-axis: Servo motor; Z-axis: Stepper motor
Lifting Mode	Carriage lifting + automatic height detection
Y-axis Drive Mode	Dual independent Y-axis motors with screw servo drive
Printing Platform	4 freely switchable zones; electronic vacuum adsorption & media positioning
Applicable Materials	Acrylic, wood board, stone, glass, metal, PVC, industrial film and other flat substrates
Overall Machine Dimension	L4622mm × W2145mm × H1550mm
Machine Weight	1145 KG
Operating Environment	Temperature: 15–30°C; Relative Humidity: 20%–80%
Total Power	5500W (Vacuum fan power: 2200W included)
Input Voltage	220VAC / 50HZ
Working Air Pressure	0.5 Mpa
